Product Advantages
l Easy installation, without any special tools.
l Maximum application microduct diameter up to 50mm.
l Captivated screws in lid portion allowing inverted installation.
Product Specifications
Construction | Description |
Materials | Shell:ABS,Spacers:Nylon,Seal Silcon,Port Supports:Polypropylene,Cap:ABS |
Dimensions | Length:615mm (24.2”) Width:159mm (6.26”) Height:108mm (4.25”) |
Weight(g) | 2040 |
Application | DB or DI |
For Duct Size(mm) | OD 50 |
Crush | 1000N/10mins |
Impact | >10 joule |
For Duct size | Lest than OD ≤50mm |
