FCST-FMC16
FCST
FCST-FMC16
50
Product Overview
With the FCST-FMC16 Field Assembly Connector Metal V-Slot Groove, single fiber termination in the field may be completed quickly and easily without the need for polishing or glue. It has excellent Zirconia ferrules and a finely made metal V-groove that guarantee a very reliable connection for a variety of network applications. Due to its small size and availability of 250um and 900um fiber singlemode options, it is also perfect for applications where space is limited.This connector offers network professionals and installers a cost-effective solution that allows them to simplify operations and lessen workload on-site thanks to its reliable performance and simple installation.
Product Advantages
Offers an easy-to-deploy fiber solution.
Requires no special tools for installation.
Pre-stubble with machine polishing ferrules.
Has a reusable termination capability of up to 10 times.
Features a precision metal V-groove and high-quality Zirconia ferrules.
Boasts a high success rate of connections with low insertion and back reflection.
Provides quick and easy fiber termination without the need for polishing or epoxy.
Comes in both 250μm and 900μm fiber singlemode options for installation flexibility.
Product Specifications
Construction | Description |
Cable Diameters | 250μm/900μm |
Plug Type | SC/APC（ total length of 52mm） |
Diameter of Fiber | 9/125μm |
Fiber Mode | SM |
IL | Typical≤ 0.20dB, Max≤ 0.40dB |
RL | UPC ≤50dB, APC ≤60dB |
Tension Test | 5N |
Operating Temperature | -20°C~+75°C |
Storage Temperature | -40°C~+85°C |
Reusable | 10times |
Every Small Bag (pcs) | 10 |
Packing | 1000pcs/cnt 15.5kg 0.015CBM(0.44*0.365*0.28m) |
Product Structure
