FCST-TH-SMC07
FCST
Product Overview
FCST-TH-SMC07 SMC/BMC Wholesale Telecom Duct Access Chamber which is specially designed to provide protection, storage, equipment installation and maintenance and other functions for the underground embedding of fiber optic splice closure and cable products. The composite manhole not only has the advantages of high stability, long service life, pressure resistance, convenient assembly, but also has the characteristics of high protection level, high reliability, which can ensure that no problems will occur in any complex environment.
Product Advantages
lDuct cahmber can be easy installation.
lLong service life.(30years)
lComposite chamber with strong corrosion resistance.
lGood resistance to high and low temperature.
lTelecom chamber have convenient transportation and cost reduction.
lTransverse and vertical cross stiffeners are arranged around the outer side of the shaft, also be closely combined with the rammed soil layer. It is not easy to move and loosen after rolling.
Product Specifications
Construction | Description |
Executive Standard | ANSI/SCTE 77 2017 |
Material | BMC |
Bearing level | Tier 15 |
Flame Retardant Grade | V0 |
Environmental Requirements LOGO | Meet ROHS Available |
Length | 1319.2mm丨51.937 in |
Width | 862mm丨33.937in |
Height | 609.6mm丨24in |
Weight | 120 kg |
Working Temperature | -40℃~+65℃ |
Storage Temperature | -40℃~+70℃ |
Product Size
External Size (L*W*H) | Internal Dimensions (L*W*H) | Manhole Cover Load Grade |
1319.2*862*609.6mm | 1219.2*762*569.6mm (48"x30"x22.425") | Tier 15 |
Ordering Information
Performance Test
Environmental Test | Ultimate Bending Strength | ANSI/SCTE 77 2017 -6.1.6 |
Chemical Resistance | ANSI/SCTE 77 2017 -6.2.6 | |
Simulate Sunlight | ANSI/SCTE 77 2017 -6.3.6 | |
Water Absorption | ANSI/SCTE 77 2017 -6.4.6 | |
Flammability | ANSI/SCTE 77 2017 -6.5.6 | |
Internal Equipment Protection Test | ANSI/SCTE 77 2017 -6.6.6 | |
Structural Load Test | Vertical Design Load Test | ANSI/SCTE 77 2017 -7 15 |
Vertical Test Load Test | ANSI/SCTE 77 2017 -7 15 | |
Transverse Design Load | ANSI/SCTE 77 2017 -7 15 | |
Vibration Test Load Test | ANSI/SCTE 77 2017 -7 15 |
Accessory
Installation Using
Name | Model | Quantity |
Inner hexagon bolts | M13 * 45 stainless steel 304(American standard) | 12 |
hexagon bolts | M13 nut stainless steel 304(American standard) | 12 |
Triangular anti-theft bolts | M8 * 62 stainless steel 304(American standard) | 8 |
English Manual | / | 1 |
Plastic bag | 160*260mm*20S | 1 |
Packing And Transportation
Disassembly and Transportation
Pallet Size | Product Weight | Pallet Capacity | Container Loading Capacity (40GP container，Weight limit 26 tons) |
FCST-TH-SMC07 (1245mmx925mmx1680mm) | 120 | 12sets | 216sets |
Product Application
Note：The practical application of this Composite Manhole Chamber, covering many fields such as municipal administration, electric power,electricity, water, road administration,and drainage.
