FCST
HDPE Micro Duct Gas Block Connector
300
Product Overview
This Gas-Water Block Micro Duct Connector is used to prevent the liquid flowing between the connected micro ducts at transformation point. Thus, avoid fluid(gas) entering the micro ducts, and damage the equipment.
Product Advantages
For 5 to 20 mm microducts.
Tube connector gas-block with easy "push-in" installation.
Crystal clear transparent body.
95% of the material is made of non-metal.
Rugged design for direct buried and above ground use.
Made of eco-friendly materials, it has passed ROHS and REACH certifications.
Product Specification
Model | D1 | D2 | A1 | A2 | B | L | Weight(g) |
GSA5 | 5 | 5 | 13.5±0.2 | 13.5±0.2 | 2.5±0.12 | 44±0.5 | - |
GSA6 | 6 | 6 | 13.5±0.2 | 13.5±0.2 | 2.5±0.12 | 44±0.5 | - |
GSA7 | 7 | 7 | 15.2±0.2 | 15.2±0.2 | 4±0.12 | 50.5±0.5 | 8.6±0.1 |
GSA7 | 7 | 7 | 15.2±0.2 | 15.2±0.2 | 4.5±0.12 | 50.5±0.5 | 8.6±0.1 |
GSA8 | 8 | 8 | 15.2±0.2 | 15.2±0.2 | 4±0.12 | 50.5±0.5 | 8.6±0.1 |
GSA8 | 8 | 8 | 15.2±0.2 | 15.2±0.2 | 4.5±0.12 | 50.5±0.5 | 8.6±0.1 |
GSA10 | 10 | 10 | 17.5±0.2 | 17.5±0.2 | 8±0.12 | 59.5±0.5 | 11.6±0.1 |
GSA12 | 12 | 12 | 21.5±0.2 | 21.5±0.2 | 8±0.12 | 64.5±0.5 | 18.6±0.1 |
GSA14 | 14 | 14 | 23.5±0.2 | 23.5±0.2 | 10±0.12 | 69.5±0.5 | 23.6±0.1 |
GSA16 | 16 | 16 | 25.3±0.2 | 25.3±0.2 | 10±0.12 | 73.5±0.5 | 35.5±0.1 |
GSA18 | 18 | 18 | 32.7±0.3 | 32.7±0.3 | 12±0.12 | 76.5±0.5 | 57.1±0.1 |
GSA20 | 20 | 20 | 32.7±0.3 | 32.7±0.3 | 13±0.12 | 76.5±0.5 | 52.6±0.1 |
Packing Information
