FCST012224
FCST
FCST012224
Product Specifications
Construction | Description |
Capacity | Bunchy: 24-288(cores), Ribbon: up to864(cores) |
Material | PP |
Dimension H*D | 513*Φ313mm |
Inlets/Outlets | 1/6 |
Installation | Pole/Wall/Aerial |
Diameter Of Fiber Cable | Φ5mm～Φ38mm |
Protection Level | IP67 |
Net Weight（g） | 4600 |
Sealing Mode | Heat Shrinkseal |
Splice Tray | 24F |
Design And Customization Services
l Provide service with whole process from blueprint to product to the customer.
l Meet customer’s requirement to customize logo in suitable place for existing product.
l Meet customer’s requirement to make reasonable modify and customization for existing product.
l Provide free design according to the requirement of customer after signed cooperative agreement.
Product Specifications
Construction | Description |
Capacity | Bunchy: 24-288(cores), Ribbon: up to864(cores) |
Material | PP |
Dimension H*D | 513*Φ313mm |
Inlets/Outlets | 1/6 |
Installation | Pole/Wall/Aerial |
Diameter Of Fiber Cable | Φ5mm～Φ38mm |
Protection Level | IP67 |
Net Weight（g） | 4600 |
Sealing Mode | Heat Shrinkseal |
Splice Tray | 24F |
Design And Customization Services
l Provide service with whole process from blueprint to product to the customer.
l Meet customer’s requirement to customize logo in suitable place for existing product.
l Meet customer’s requirement to make reasonable modify and customization for existing product.
l Provide free design according to the requirement of customer after signed cooperative agreement.
