FCST080120
FCST
Product Overview
FCST080120 Mini VFL Power Meter is a high precision, mini type optical fiber engineering application instrument.
Product Advantages
l High precision，low error，large dynamic range.
l Mini type ergonomic design，single hand operation，flexible and convenient to use.
l OLED HD full view display screen.
l 2.5mm Universal adapter.
l Wavelength memory function.
l micro-USB power supply.
l Auto power-off，energy-saving.
l 6 calibrated wavelength.
l Support lanyard，falling/losing-proof.
l Support dBm, dB，mW unit switching.
Product Application
l Optical fiber CATV network.
l Optical fiber communication engineering.
l Research on optical fiber sensing.
l Optical devices manufacturing.
Product Specifications
Model | FCST080120A | FCST080120C |
Wavelength Range（nm） | 850~1700 | |
Detector Type | InGaAs | |
Measurement Range（dBm） | -70～+6 | -50～+26 |
VFL | 10mW | |
Uncertainty（dB） | ±0.3 | |
Calibrated Wavelength（nm） | 850,1300,1310,1490,1550,1625 | |
Display Resolution（dB） | 0.05 | |
Operating Temperature（℃） | -10~+60 | |
Storage Temperature（℃） | -25~+70 | |
Auto-off Time（min） | 10 | |
Battery Operating Time（h） | ≥130 | |
Power Supply | 3*AA 1.5V/micro USB | |
Weigh（g） | 70 (without battery) | |
Dimensions（mm） | 128x52x22 | |
Note:
①Wavelength range: specify a standard operating wavelength range from λmin to λmax, and the optical power meter designed in this wavelength range work s well within specified parameters.
②Power measurement range: the range of the maximum optical power can be measured according to the specified index.
③Uncertainty:The error between the measured results of a certain optical power and the standard optical power test results.
Standard Packages
Model | Includes |
All FCST0801020 Models | FCST080120 Mini VFL Power Meter、User manual、Certificate |
