FCST-FDR Fiberglass Duct Rodder

  • Ducting rodder is coated by high density polyethylene engineering plastic as its protected layer.
  • Which makes the duct rodder cover sliding on surface, durable, corrosion resistant and has good insulation performance.
Availability:
Quantity:
  • FCST FDR

  • FCST

  • FCST FDR

Product Overview

FCST-FDR Fiberglass duct rodder is selected as a special tool for pulling electric cables and optical fiber cables in telecom, power industries, buildings and many other fields. The rod is made of fiberglass and high strength resin at high temperature, it is coated by high density polyethylene engineering plastic as its protected layer, which makes the duct rodder cover sliding on surface, durable, corrosion resistant and has good insulation performance, these make it safe for using in cable occupied duct. Along with pull head and handcart, it features easy to move and operate.The FRP push pull rod will be equipped with different size of reels in accordance with the length of the rod, there are wheels on the reel to make it convenient for moving, it is an ideal tool for laying cables.

Product Advantages

Inner Core is E-Glass Fiber.

Fiberglass rod is lightweight and flexible.

Rod material is FRPI import solid core material.

There are kinds of colors and size for the rod to choose.

Outer protect layer are made of high density polyethylene and import material.

Used to install pulling ropes and winch ropes into ducts,ready for cable pulling operations.

Product Specifications

Construction

Description

Product Name

FCST-FDR Fiberglass Duct Rodder

Rod Diameter (mm)

4.5~16mm(Customized)

Rod Length (m)

10~350m(Customized)

Frame Spec. (mm)

1300*450*1330,1200*420*1220,980*350*1000,680*240*700,420*180*400(Customized)

Material

Construction

Description

Fiber Glass Rod Inner

FRP

Fiber Glass Rod Outer

PP

Metal Frame

Steel with high-temperature sprayed plastic or hot dip galvanized

Physical Property

Construction

Description

Fiber Glass Content

75-80%

Density

> 1.9gr/cm3

Working Environment

-40to +80

Minimum Pulling Strength

4000N +/-5%

Consistency Of Rod

137gr/m

Flexural Modulus

> 46.500Mpa

Elongation At Break

2.5-3%

Rod Specifications



FCST-FDR Fiberglass Duct Rodder_02

Rod Dia.(mm)

Inner Core Dia.(mm)

Jacket Thickness
(mm)

Bend Radius

(mm)

Max. Tensile Strength
(KN)

Max. Bending Force
(KN)

4.5

3.0

0.75

100

-

0.205

5

4.0

0.5

100

-

-

6

4.0

1.0

100

-

0.396

7

6.0

0.5

150

2.67

0.825

8

6.0

1.0

150

2.67

0.825

9

7.0

1.0

160

16.48

1.01

10

8.0

1.0

178

19.66

1.18

11

8.0

1.5

390

19.66

1.18

12

8.5

1.75

450

-

-

13

10

1.5

500

25.36

1.76

14

10

2.0

550

25.36

1.76

15

12

1.5

600

29.54

2.85

16

12

2.0

650

29.54

2.85

Ordering Information

FCST-FDR Fiberglass Duct Rodder_03

Accessories Optional

FCST-FDR Fiberglass Duct Rodder_04

Package Information

FCST-FDR Fiberglass Duct Rodder_05
